Product Description

Palmer Fixture HD0935 EcoTap Deck Mount High Speed Hand Dryer

Create a cleaner, clutter-free washroom experience with the new EcoTap high speed hand dryer from Palmer Fixture! Users can dry their hands right after they wash them while excess water goes right into the sink. Fast 10 – 15 second dry time with a stylish satin finish.

• Creates a cleaner, clutter-free washroom experience
• Excess water goes right into the sink
• 10-15 second dry time
• Easy to clean and low maintenance
• Intelligent temperature control technology
• Smart air outlet design
• Sound and power adjustment
• Standard deck opening diameter: 35mm
• Carbon filter assembly

Specifications

Model # / Color:

• HD0935-09 / Brushed Stainless

Dimensions:

Above Counter

• Width: 1.97"
• Height: 6.69"
• Depth: 8.66"

Below Counter

• Width: 12.05"
• Height: 7.60"
• Depth: 5.85"

Weight:

• 13.89 lbs

Motor Type: Brush Type, Dual Ball Bearings

Thermal Protection:
Thermostat shuts off at 203°F (95°C)
Heater shuts off at 185°F (85°C)

Operating Airflow: 16,535-19,882 LFM, Adjustable

Air Output Temperature:
122°F (57°C), Adjustable
Ambient Temp 77°F (25°C)

Sound Level: MIN 68.5dB to 70.5dB MAX @1m

Isolation: Class 1

Drip Proof: IP35

Watts: 500W

RPM: 22,000 - 29,000, Adjustable

Voltage & Amps:
HD0935-09 - 110/120V / 7.6-8.4A

Product Description

Palmer Fixture HD0945 EcoStorm Recessed High Speed Hand Dryer

The new and improved EcoStorm HUSH is one of the quietest high speed hand dryers in the industry, with a decibel rating of 63.5dB.

The EcoStorm uses 90% less energy than conventional hand dryers and there is up to 97% cost savings versus paper towel use.

• 10-15 second dry time, with automatic touch-free operation
• Quieter than most high speed hand dryer on the market
• Over 75% cost savings vs. conventional hand dryers
• Uses 90% less energy vs. conventional hand dryers
• 1-piece cover with 2 vandal-resistant lock screws
• Operates on only 1000 watts
• Manufactured using recycled materials
• 3 Year Warranty

Specifications

Model # / Color:

• HD0945-09 / Brushed Stainless

Dimensions & Weight:

• Width: 10-45/64"
• Height: 15-17/32"
• Depth: 5-1/2"
• Weight: 15.4 lbs

Motor Type: 3/4 HP, 500W Brush Type, Dual Ball Bearings

Thermal Protection:
Motor shuts off at 221°F (105°C)
Heater shuts off at 282°F (139°C)

Operating Airflow: 17,752 LFM

Air Output Temperature:
131°F (55°C)
Ambient Temp 77°F (25°C)

Sound Level: 63.5dB

Isolation: Class 1

Drip Proof: IPX1

Watts: 1000W

RPM: 29,000

Voltage & Amps:
110/120V / 8.4-10.5A

Product Description

Palmer Fixture HD0955 BluStorm 2 Recessed High Speed Hand Dryer

With advancements in technology and improvements to hand dryers, more and more people are switching do to environmental benefits, cost savings and hygiene.

The stainless steel BluStorm High Speed Hand Dryer provides a 95% cost savings vs. paper towels. Be blown away! The BluStorm offers a 10-15 second dry time and a decibel rating of 77±3dB.

• Fast results with less noise, 10 second dry time
• 1-piece cover with double vandal-resistant screws and key wrench
• Power cuts off automatically after 60 seconds of irregular use
• 70% cost savings vs. conventional hand dryers
• 94% cost savings vs. paper towels
• Blue light allows use to maximize dryers efficiency
• Optional air filter available
• 5 Year Warranty

Specifications

Model # / Color:

• HD0955-09 / Brushed Stainless

Dimensions & Weight:

• Width: 9-35/64"
• Height: 20-3/16"
• Depth: 7-1/8"
• Weight: 20.7 lbs

Motor Type: 15/16 HP, 700W Brush Type, Dual Ball Bearings

Thermal Protection:
Motor shuts off at 275°F (135°C)
Heater shuts off at 221°F (105°C)

Operating Airflow: 19,680 LFM

Air Output Temperature:
113°F (45°C)
Ambient Temp 68°F (20°C)

Sound Level: 77±dB

Isolation: Class 1

Drip Proof: IPX1

Watts: 1600W

RPM: 12,000 - 18,000, Adjustable

Voltage & Amps:
110/120V / 12.5-13.4A

Product Description

Palmer Fixture RD0028 Two-Roll Standard Tissue Dispenser

The Two Roll Standard Tissue Dispenser with a plastic back is easy to use and install. The dispenser uses standard toilet tissue paper up to 5" in diameter with a 1-1/2" core. Access to reserve roll is accessible once lower roll is compeltely used. Unit features a translucent cover to allow view of paper supply and a durable lock prevents theft.

• Simple modern space-saving design
• Heavy duty lock helps prevent theft
• Allows user to completely use one roll before transferring to the next

Specifications

Model # / Color:

• RD0028-01 / Dark Translucent


Dimensions & Weight:

• Width: 6"
• Height: 13"
• Depth: 5-3/4"
• Weight: 2 lbs

Capacity: Two 4-1/2" W x 5-1/4" D Rolls (1-1/2" Core)

Key Type: 1

Product Description

Palmer Fixture RD0044 4-Roll Carousel Tissue Dispenser

The 4-Roll Carousel Standard Tissue Dispenser features a roll advance mechanism that ensures that a roll must be completely used before switching to a new one. The easy loading dispenser is fully enclosed for maximum hygiene and the locked hinged cover eliminates theft and waste. This unit holds any standard household tissue roll with a 1-1/2" core.

• 4 station conventional tissue carousel
• Efficient roll advance mechanism
• Towel is completely covered for maximum hygiene
• Vandal-proof, break resistant, chemical and flame resistant
• Made of tough impact resistant material
• Translucent cover allows for view of paper supply

Specifications

Model # / Color:

• RD0044-01 / Dark Translucent

Dimensions & Weight:

• Width: 13-1/2"
• Height: 14-3/4"
• Depth: 6-1/4"
• Weight: 4 lbs

Capacity: Four 4-1/2" W x 5-1/4" D Rolls (1-1/2" Core)

Key Type: 2

Product Description

Palmer Fixture RD0325 Metal Two Roll Standard Tissue Dispenser

The Standard Double Roll Tissue Dispenser features a sleek stainless steel finish that will fit nicely into any restrooms decor. Fits two standard toilet tissue rolls with a minimum 1-1/2" core. The heavy duty lock prevents theft and vandalism. Design allows user to completely use one roll before transferring to the next. Heavy gauge steel construction is designed for maximum strength and durability.

• Sleek stainless steel finish for a modern look
• Holds two standard toilet tissue rolls
• Heavy duty lock to prevent theft and vandalism
• Heavy gauge steel construction

Specifications

Model # / Color:

• RD0325-09 / Brushed Stainless

Dimensions & Weight:

• Width: 6"
• Height: 13-3/4"
• Depth: 5-3/4"
• Weight: 4.50 lbs

Capacity: Two 4-1/2" W x 5-1/4" D Rolls (1-1/2" Core)

Key Type: 1

Product Description

Palmer Fixture RD0327 Twin 9" Jumbo Tissue Dispenser

The Twin 9" Jumbo Roll Tissue Dispenser in a stainless steel finish, it universal for all brands of 9" jumbo roll tissue. A sliding panel ensures the use of one roll at a time. A double-latch lock prevents theft and waste.

• Modern brushed stainless finish
• Universal for all brands of Jumbo Roll Tissue with 3-3/8" cores
• Comes with a 2-1/4" core, includes a 3-3/8" adaptor
• Sliding panel ensures the use of one roll at a time
• Double-latch lock prevents theft
• Windows on the front of the dispenser allow for easy viewing of the paper level

Specifications

Model # / Color:

• RD0327-09 / Brushed Stainless

Dimensions & Weight:

• Width: 20-1/4"
• Height: 10-3/8"
• Depth: 4-1/4"
• Weight: 6.75 lbs

Capacity: Two 9" Rolls (2-1/4"-3-3/8" Core)

Key Type: 1

Product Description

Palmer Fixture RD0330 Single 13" Jumbo Tissue Dispenser

The RD0330 Single 13" Jumbo Roll Tissue Dispenser holds universal brands of jumbo tissue with a 3-3/8" core. Tissue is covered for maximum hygiene. Translucent cover enable easy detection of low paper supply.

• 13" Single Roll Jumbo Tissue Dispenser
• Tissue is covered for maximum hygiene and efficiency
• Translucent cover allows for a view of the paper supply
• Durable lock prevents theft and waste
• ADA Compliant

Specifications

Model # / Color:

• RD0330 / Black Translucent

Dimensions & Weight:

• Width: 16-1/4"
• Height: 14-1/2"
• Depth: 5"
• Weight: 3.25 lbs

Capacity: 13" Roll (3-3/8" Core)

Key Type: 1

Product Description

Palmer Fixture RD0381 Standard One Roll Tissue Dispenser

The Standard Single Roll Tissue Dispenser features tension springs to reduce paper from free spinning. The units are easy to load and servce, and have concealed self-locking mechanisms to prevent theft. Rolls must be a minimum 1-1/2" core.

• Tension springs reduce paper from free spinning
• Easy to load and service
• Concealed self-locking mechanism to prevent theft
• Minimum 1-1/2" core diameter

Specifications

• Tension springs reduce paper from free spinning
• Easy to load and service
• Concealed self-locking mechanism to prevent theft
• Minimum 1-1/2" core diameter

Product Description

Palmer Fixture RD0384 Standard Two Roll Tissue Dispenser

The Standard Double Roll Tissue Dispenser features tension springs to reduce paper from free spinning. The units are easy to load and servce, and have concealed self-locking mechanisms to prevent theft. Rolls must be a minimum 1-1/2" core.

• Tension springs reduce paper from free spinning
• Easy to load and service
• Concealed self-locking mechanism to prevent theft
• Minimum 1-1/2" core diameter

Specifications

Model # / Color:

• RD0384 / Bright Chrome

Dimensions & Weight:

• Width: 11-3/4"
• Height: 4-1/4"
• Depth: 2-3/4"
• Weight: .92 lbs

Capacity: Two 4-1/2" W x 5-1/4" D Rolls (1-1/2" Core)

Product Description

Palmer Fixture SE0800-09 Electronic Touchless Bulk Soap Dispenser

The Electronic Touchless Bulk/Cartridge Soap Dispenser in brushed stainless, consistently dispenses one (1-1.5ml) drop at a time. The unit operates on 4 "AA" batteries for up to 15,000 cycles. The refillable reservoir may be used with quality bulk liquid soaps. The mechanism is a separate piece to prevent damage from the soap.

• Automatic Operation
• Brushed stainless finish
• Consistently dispenses one 1-1.5ml drop at a time
• Operates on 4 "AA" batteries
• Vandal resistant security lock and key
• Reservoir can be used with quality bulk soaps
• Key components are independent for easy maintenance

Specifications

Model # / Color:

• SE0800-09 / Brushed Stainless

Dimensions & Weight:

• Width: 4-1/2"
• Height: 10-1/2"
• Depth: 4-1/4"
• Weight: 2.58 lbs

Capacity: 800ml Liquid Soap

Batteries: 4 "AA" Sized Alkaline

Key Type: 4

Product Information

Palmer Fixture SP0100-00 Key for Dispensers

Dispenser Compatibility

Dispenser Compatibility

Product Information

Palmer Fixture SP0105-00 Key for Dispensers

Dispenser Compatibility

Product Information

Palmer Fixture SP0102-00 Key for Dispensers

Dispenser Compatibility

Product Information

Palmer Fixture SP0100-00 Key for Dispensers

Dispenser Compatibility
